Adjustable rolling pressure Auto loading and unloading, Semi auto loading and unloading Direction reversibility and change of speed and rotation of pressing roller Recognition of completed loadage and sense of product separation
[ Technical Data ]
POWER SUPPLY MAX. POWER CONSUMPTION PRESSURE FORCE (ADJUSTABLE) STANDARD ROLLERS CAMBER ROLLES DIAMETER TENSIONING BLADE DIAMETER
LOADING Q'TY LOADING SPEED AIR CONSUMPTION
: 220/380V, 50Hz/60Hz, 3 Phase
: 5 KVA
: FROM 100 TO 3,000KG
: 125 RADIUS
: 95MM
: 200MM to 500MM (Auto)
500MM to 900MM (Semi-Auto)
: 50 EA
: 10SEC/EA
: 50L/MIN.
